MOBILE SANDBLASTING POT TECHNICAL DATA |
Volume Of the Pressure Sandblasting Pot |
300 lt |
Working Pressure of the Sandlasting Pot |
4-10 BAR |
Test Pressure of the Sandblasting Pot |
16 BAR |
Air Intake of Mobile Sandblasting Pot |
1 1/4" |
Weight of the Mobile Sandblasting Pot |
180 Kg |
Air Consumption |
3-4 m3/min (6-8 BAR) |
Height of the Portable Sandblasting Pot |
1,60 mt |
Diameter of the Portable Sandblasting Pot |
64 cm |
Sandblasting Pot Valve |
Nodular Cast Iron |
Compliance of Mobile Sandblasting |
Approve |
SANDBLASTING ABRASIVES THAT CAN BE USED AT MOBILE PRESSURE SANDBLASTING POT |
TYPE |
FEATURE |
PURPOSE OF USAGE |
Aluminum Oxide |
Hard, Angular |
Roughening, Paint Removal |
Glass Beads |
Hard, Spherical |
Finishing, Polishing |
Garnet |
Hard, Angular, Economic |
Roughening, Paint Removal |
Steel Shot |
Hard, Spherical, Economic |
Tension Relieving, Cleaning |
Stainless Steel Shot |
Hard, Spherical |
Finishing, Polishing, Tension Relieving |
Silicon Carbide |
Hard, Angular |
Roughening, Paint Removal |
Ceramic Shot |
Hard, Spherical |
Finishing, Polishing |
Glass Sand |
Hard, Angular |
Roughening, Paint Removal |
Steel Grit |
Hard, Angular, Economic |
Roughening, Paint Removal |
Silica Sand |
Hard, Angular, Economic |
Roughening, Paint Removal |
|
SK 300 Automatic Pressure Sandblasting Pot (Portable Sandblasting Pot) is produced by combining the best quality sandblasting equipment and hydrostatic tested. It provides surface sandblasting opportunity up to 30 m2 per hour. The sandblasting process to create the desired effect on the surface with the pressure sandblasting pot, 3-4 cubic meter of abrasive and air mixture per minute at 6-8 bar sprayed with pressure on the surface. The sand put into the sandblasting pot flows to the valve at the bottom. Sandblasting abrasive and compressed air which entered separately to this valve goes to the hose as "mixed". This mixture is advancing rapidly in the blasting hose, come to the nozzle (inner diameter of approximately 6-8 mm), compressed and sprayed out of the nozzle very strongly. The working principle of the portable sandblasting pot can be summarized in its simple form in this way. Our sandblasting pot has the ability to perform wet sandblasting after the necessary arrangement has been made.We recommend that the pressure sandblasting system and our SK 300 Automatic Portable Sandblasting Pot be operated by taking the necessary precautions to protect human and environmental health.
|
|
SANDBLASTING SILO
|
For your sandblasting silo needs; We produce in different capacities such as 1,0
00 lt, 3,000 lt, 4,000 lt and 6,000 lt. You can call us for your sandblasting pot and sandblasting silo needs and get a quote immediately.
|
|
